BCN2-Zeiss 0.5X C-mount Adapter for Zeiss Microscope

BCN2-Zeiss TV Adapter


Product Detail

Download

Quality Control

Product Tags

Feature

1. Convert the Zeiss trinocular microscope phototube/head/port (have standard ISO 30 mm(1.18 inch) outer diameter for the insertion end to phototube) to traditional C-Mount type(25.4 mm or 1 inch diameter with 32 threads per inch);
2. With different built-in reduction lens (1.2X,1X, 0.8X, 0.65X, 0.5X) for achieving better field of view from microscope trinocular head(suitable for 4/3” 1”, 2/3”, 1/1.8”, 1/2”, 1/2.5” inch CCD or CMOS sensor chips);
3. Can be installed in Zeiss UIS trinocular tube such as Axio series microscope;
4. Build of material: anodized aluminum;
5. Telecentric optics with low light deficiency;
6. Parfocal with different microscope objective lenses;
7. Diffraction limited MTF;
8. Aperture totally coupled with UIS microscope objective’s exit pupil.

Specifications

Model


Magnification

Sensor Size

Mount Type

BCN2-Zeiss 1.2X

BCN2-Zeiss 1.2X

1.20X

1”, 4/3”

T2-Mount

BCN2-Zeiss 1.0X

BCN2-Zeiss 1X

1.0X

1”, 2/3”

C-Mount

BCN2-Zeiss 0.8X

BCN2-Zeiss 0.8X

0.80X

1”,2/3”

C-Mount

BCN2-Zeiss 0.63X

BCN2-Zeiss 0.63X

0.63X

2/3”,1/1.8”,1/2”

C-Mount

BCN2-Zeiss 0.5X

BCN2-Zeiss 0.5X

0.50X

1/1.8”,1/2”,1/2.5”

C-Mount

Supported Microscope Axio Examiner.A1; Axio Examiner.D1; Axio Examiner.Z1;Axio Imager Vario; Axio Imager.A1; Axio Imager.A1m; Axio Imager.A2; Axio Imager.A2m; Axio Imager.D1; Axio Imager.D1 for epi-fluorescence with ApoTome equipment; Axio Imager.D1m; Axio Imager.D2; Axio Imager.D2m;

Axio Imager.M1 (Axio Imager.M1 for KS ELISPOT); Axio Imager.M1m; Axio Imager.M2; Axio Imager.M2m; Axio Imager.Z1; Axio Imager.Z1 + ApoTome; Axio Imager.Z1m; Axio Imager.Z2; Axio Imager.Z2m;

Axio Lab.A1; Axio Lab.A1 FL-LED; Axio Lab.A1 MAT; Axio Lab.A1 Pol;

Axio Observer.A1; Axio Observer.A1 Entry; Axio Observer.D1; Axio Observer.D1 Entry; Axio Observer.D1 Mid Range; Axio Observer.Z1; Axio Observer.Z1 High End;

Axio Scope.A1; Axio Scope.A1 Pol; Axio Scope.A1 Vario; Axio Vert.A1;

Axio Vert.A1 FL; Axio Vert.A1 FL-LED; Axio Vert.A1 MAT;

Axio Zoom.V16;

PALM CombiSystem Rel. 4.2; PALM MicroBeam; PALM MicroBeam Rel.4.2; PALM MicroTweezers Rel.4.2;

Stemi 508 doc; Stemi 508 trino;

SteREO Discovery.V12; SteREO Discovery.V8; SteREO Lumar.V12;
